Description
Customizable Industrial RO Water Plant Reverse Osmosis
Product description
- Pressure: 0.8~1.2MPa
- PH range: 5.5 ~ 8.5
- Applicable temperature: 5~40°C
- Feed Water TDS: ≤1000PPM
- Desalination rate: ≥98%
- Recovery rate: ≥50%
- Organic matter removal rate: ≥99%
- Bacterial removalrate: ≥99.9%
Reverse Osmosis Ro System Water Features
- High-precision filter, the pore size is nanometer, the best water quality
-
Automatic switching of manual/electric control system;
-
With self-check function, automatic boiling water system without water point, water full stop, no pressure protection and other safety devices;
- With open RO membrane automatic cleaning and automatic double cleaning of the water tank, it can extend the service life of the RO membrane;
-
With online water quality monitoring (conductivity display), flow and pressure online display functions;
- Equipment integration, simple installation, simple operation, no special responsibilities; Equipment failure has an automatic alarm function;
- High water production, high desalination rate and long service life;
- Core components (pumps, reverse osmosis membranes, electronic control systems, etc.) imported/domestic joint venture brands; The equipment rack is made of stainless steel, the low-pressure pipe is made of UPVC, and the high-pressure pipe is made of SUS304 stainless steel.
Reverse Osmosis Ro System Water Process
1. Raw water pump-- provide the pressure to quartz sand filter/active carbon filter.
2.Quartz sand filter-- get rid of turbidity, suspended matter, organic matter, colloid.
3. Active Carbon filter--Remove the color, free chloride, organic matter, harmful matter.
4. Softener(Optional)--exchange "ions" of calcium and magnesium with the most common and easiest method.
5. Security filter--prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um.
6. High pressure pump-- Provide the high pressure to RO membrane .
7.RO Reverse Osmosis Unit -- main part of the plant. RO membrane's desalting rate can reach 99%.
8. Storage Tank, Achieve treatment effect.
Reverse Osmosis Ro Systems Case
