304 316 Single Micro Filter Bag Cartridges 40 Inch Housings

  • Product Item：Filter Cartridge Housings
  • Material:304 316
  • Pressure:0-1.6Mpa
  • Capacity :0-100m3hr
  • stainless steel filter cartridge
    • doe cartridge filter housing  , wholesale Single  , 3  , 5  , 8  , multi  , precision  , bag basket housings  , stainless steel filter  , Cartridge Filter Housings
    Inquiry Send Email

    Description

    Products Description

    What Is Cartridge Filter Housing?

    Filtergehäuse Edelstahl SS Filter Housing consists of SUS316L or SUS304, and take filter cartridge as its element. The SS filter
    housing can be used for filtration of liquid, gas and 0.1um above particles and bacteria, with high removal rating and flow rate.
    It possess properties of lower absorption, no medium shedding, no leakage, acid and alkali Resistance, and corrosion resistance.



    Technical filter housing
    Seal type: O-rings and flat gasket Sealing material: nitrile rubber(chemitum), silicone, fluorine rubber, usually use silicon
    rubber seal Filter interface: the threaded, clamp(hoop), GB, HG, DIN, ANSI, JIS standard flange Filtration accuracy: 1μm - 100 μm
    Body material: SS304/SS 316
    Optional Parts
    Item
    Size
    Available
    Application
    DJ-DOE
    10''/20''/30''/40''
    √
    Pharmaceutical industry: pre-filtration of various antibiotics.
    Oil industry: oilfield water injection filtration.
    DJ-222
    10''/20''/30''/40''
    √
    Food and beverage industry: filtration of alcohol, mineral water, drinking water.
    Electronics industry: high purity water pre-filtration.
    DJ-226
    10''/20''/30''/40''
    √
    Chemical industry: filtration of various organic solvents, acids and alkali.
    Technical Paramenters

    DAGYEE Cartridge Housings

    Commercial and industrial filter housing liquid containers are ideal for chemical systems, commercial RO and membrane water treatment systems for pre-filtration, high-purity water, post-filtration, food and beverage, industrial facilities, etc.

    We always have a large stock of stainless steel liquid housings for commercial and industrial use. Most of the models shown are available from stock immediately.


    DAGYEE Cartridge Housing Feature

    • Low pressure drop
    • Permanently piped filter housing open without special tools and without disturbing the piping
    • Machined cover gasket groove provides positive O-ring sealing
    • Easy to clean
    • In-line inlet and outlet
    • Stainless steel internals
    • Standard Options
    • Carbon steel, 304 or 316 stainless steel housings
    • Accommodates 10, 20, 30 or 40-inch cartridge

    Cartridge Housing Technical

    Model Size Dimension mm Flow m3/hr Inlet Outlet Pressure
    DPF-10-170 10'' 170*430 1-2 1'' 0.6Mpa
    DPF-10-200 10'' 200*430 2-3 1'' 0.6Mpa
    DPF-20-170 20'' 170*690 3-4 1'' 0.6Mpa
    DPF-20-200 20'' 200*690 4-6 1 1/2'' 0.6Mpa
    DPF-20-250 20'' 250*690 6-8 2'' 0.6Mpa
    DPF-30-200 30'' 200*940 7-8 1 1/2'' 0.6Mpa
    DPF-30-250 30'' 250*940 10-11 2'' 0.6Mpa
    DPF-40-200 40'' 200*1240 9-11 2'' 0.6Mpa
    DPF-40-250 40'' 250*1240 13-15 2'' 0.6Mpa
    DPF-40-300 40'' 300*1350 14-18 2'' 1.0Mpa
    DPF-40-320 40'' 320*1350 16-20 2'' 1.0Mpa
    DPF-40-350 40'' 350*1350 20-30 2 1/2'' 1.0Mpa
    DPF-40-400 40'' 400*1430 30-40 3'' 1.0Mpa
    DPF-40-450 40'' 450*1450 50-65 3'' 1.0Mpa


    DAGYEE Cartridge Housing Removal

    • Suspended matter
    • Algae
    • Impurities
    • Fine particles
