  • LW Horizontal Screw Conveyor Drilling Mud Decanter Centrifuge
  • LW Horizontal Screw Conveyor Drilling Mud Decanter Centrifuge
  • LW Horizontal Screw Conveyor Drilling Mud Decanter Centrifuge
  • LW Horizontal Screw Conveyor Drilling Mud Decanter Centrifuge
LW Horizontal Screw Conveyor Drilling Mud Decanter Centrifuge LW Horizontal Screw Conveyor Drilling Mud Decanter Centrifuge LW Horizontal Screw Conveyor Drilling Mud Decanter Centrifuge LW Horizontal Screw Conveyor Drilling Mud Decanter Centrifuge

LW Horizontal Screw Conveyor Drilling Mud Decanter Centrifuge

  • Product Item:LW400-1800
  • Voltage: 380V 3phase 50Hz or OEM
  • Capacity: 2-12 M3/h
  • Warranty: 1.5 years
  • MOQ: 1set
  • Solid Bowl Decanter Centrifuge  , Mud Decanter Centrifuge  , Juice Decanter Centrifuge  , High Speed Centrifuge Separator  , Horizontal Decanter Centrifuges
    Inquiry Send Email

    Description

    WHAT IS CENTRIFUGE DECANTER


    Centrifuge is the use of centrifugal force, the separation of liquid and solid particles or liquid and liquid mixtures in the components of the machine.

    The size and size of centrifugal force are determined by rotation speed, rotation radius and melting mass of material.

    Centrifuges are widely used in chemical engineering, petroleum, food processing, pharmaceutical, mineral processing engineering, carbon, water treatment, nuclear energy industry and shipping and other sectors.


    Best Wastewater Decanter Centrifuge System


    HOW DOES IT WORK


    Centrifuge is the use of centrifugal force, the separation of liquid and solid particles or liquid and liquid mixtures in the components. Centrifuge is to use the powerful centrifugal force generated by the high-speed rotation of the centrifuge rotor to speed up the sedimentation rate of particles in the liquid and separate the matter with different sedimentation coefficient and buoyancy density in the sample.


    The main principle of the sedimentation centrifuge is to speed up the sedimentation speed of different specific gravity components (solid or liquid phase) in the mixture through the powerful centrifugal force generated by the high-speed rotation of the rotor, and separate the substances with different sedimentation coefficient and buoyancy density in the sample.




    CENTRIFUGE DECANTER APPLICATIONS


    3 Phase Horizontal Decanter Centrifuges

    • Waste water treatment
    • food processing
    • Petrochemical
    • Petroleum
    • Waste recycling
    • Fish processing
    • Chemicals
    • Beneficiation
    • Organic Chemicals
    • Polymer industry
    • Inorganic chemical industry


    CENTRIFUGE DECANTER TECHNICAL

    Model
    Drum diameter
    mm
    Length
    mm
    Maximum speed
    rpm
    Hightest separation
    factor g
    Mixture capacity
    m3/h
    Motor Power
    Kw
    Host weight
    Kg
    Dimension(L*W *H)
    mm
    LW250-900 250 900 5000 3500 0.5-3 11/5.5 1100 2300*700*1300
    LW350-1500 350 1500 3800 2850 1-5 18.5/5.5 2200 3500*1000*1300
    LW400-1200 400 1200 3400 2581 1-8 22/7.5 2200 3350*1000*1100
    LW400-1600 400 1600 3400 2581 2-10 22/7.5 2400 3850*1000*1250
    LW400-1800 400 1800 3400 2581 2-12 22/7.5 2500 4000*1000*1250
    LW450-1800 450 1800 3200 2572 5-20 30/7.5 3000 4200*1170*1350
    LW450-2000 450 2000 3200 2572 5-25 30/7.5 3300 4400*1170*1350
    LW530-2280 530 2280 2800 2350 10-50 45/15 4000 4750*1300*1500
    LW600-2400 600 2400 2600 2265 15-65 55/18.5 5000 4800*1350*1950
    LW650-2600 650 2600 2400 2100 20-80 55/90 6500 4900*1450*1650
    LW720-2500 720 2500 2200 1950 25-90 75/90 7000 5000*1600*1700
    LW800-2560 800 2560 2000 1800 30-100 90/132 8000
