Description
Decanter centrifuge descriptions
The DAGYEE decanter centrifuge is engineered to deliver exceptional performance in continuous solid-liquid separation. Whether you are dewatering sludge in municipal wastewater treatment, processing food products, or handling industrial minerals, our centrifuge ensures maximum separation efficiency, dry solids discharge, and clear liquid output. Experience reliability and productivity with every run.
Experience
maximum solid-liquid separation efficiency
- High-performance separation, resulting in high-value products and low waste management costs
- Lower energy consumption and carbon footprint
- Minimal maintenance costs thanks to continuous operation, high-grade machine materials, smart design and well-thought preventive services
- Low capital cost/capacity ratio
- Wide-ranging feed variations and controllable performance
How does a decanter centrifuge work?
A decanter centrifuge operates on the principle of sedimentation and high-speed centrifugal force.
-
High-Speed Rotation: The bowl rotates at high speed, generating centrifugal force up to 3000-4000 G.
-
Sedimentation: Solid particles, being denser, settle against the bowl wall.
-
Differential Speed: The internal screw conveyor (scroll) rotates at a slightly different speed, pushing the settled solids towards the conical end for discharge.
-
Liquid Discharge: The clarified liquid overflows from the opposite end via adjustable weir plates.
This continuous process ensures uninterrupted operation and high throughput.
Decanter centrifuge specifications
| Parameter | Range / Details |
|---|---|
| Bowl Diameter | 220 mm – 550 mm |
| Length/Diameter Ratio | 2.5 – 4.5 (High L/D for better clarification) |
| Max Speed | Up to 4000 RPM |
| Max G-Force | Up to 4000 G |
| Material | Duplex Stainless Steel / SS316L (Contact parts) |
| Drive System | Backdrive with VFD (Variable Frequency Drive) |
| Application | Sludge dewatering, chemical, food, mining, etc. |
| Model |
Drum diameter mm |
Length mm |
Maximum speed rpm |
Highest separation factor g |
Mixture capacity m³/h |
|---|---|---|---|---|---|
| LW250-900 | 250 | 900 | 5000 | 3500 | 0.5-3 |
| LW350-1500 | 350 | 1500 | 3800 | 2850 | 1-5 |
| LW400-1200 | 400 | 1200 | 3400 | 2581 | 1-8 |
| LW400-1600 | 400 | 1600 | 3400 | 2581 | 2-10 |
| LW400-1800 | 400 | 1800 | 3400 | 2581 | 2-12 |
| LW450-1800 | 450 | 1800 | 3200 | 2572 | 5-20 |
| LW450-2000 | 450 | 2000 | 3200 | 2572 | 5-25 |
| LW530-2280 | 530 | 2280 | 2800 | 2350 | 10-50 |
| LW600-2400 | 600 | 2400 | 2600 | 2265 | 15-65 |
| LW650-2600 | 650 | 2600 | 2400 | 2100 | 20-80 |
| LW720-2500 | 720 | 2500 | 2200 | 1950 | 25-90 |
| LW800-2560 | 800 | 2560 | 2000 | 1800 | 30-100 |
| LW800-3200 | 800 | 3200 | 2000 | 1800 | 30-110 |
| LW900-3200 | 800 | 3200 | 1800 | 1650 | 30-150 |
Why
choose the DAGYEE decanter centrifuge ?
-
Proven Reliability: Thousands of units operating worldwide in demanding environments.
-
High Efficiency: Advanced bowl and scroll designs maximize solids recovery and liquid clarity.
-
Energy Saving: Optimized drive system reduces power consumption.
-
Customizable: Tailored solutions for specific materials and process requirements.
-
Global Support: Comprehensive after-sales service and spare parts availability.
Decanter centrifuge key features
|
Bowl Body |
316L Duplex Stainless Steel |
|
Conveyor / Auger |
316L Duplex Stainless Steel with Tungsten Carbide Hard Surfacing |
|
Vessel / Collecting Cover |
316L Duplex Stainless Steel |
|
Gearbox |
Hardened Steel - Planetary Gearbox |
|
Base Frame |
Carbon Steel with Epoxy Base and Top Coat Paint |
- Robust Construction: Contact parts made from high-strength duplex stainless steel for superior wear and corrosion resistance.
- Wear Protection: Replaceable wear liners on the scroll and discharge ports extend service life.
- Large L/D Ratio: Provides longer settling time for finer particle separation.
- Deep Pond Design: Increases clarification area for better liquid quality.
- VFD Control: Precise control over differential speed to adapt to varying feed conditions.
Decanter centrifuge advanced operation capabilities
-
Fully Continuous Operation: Automatic discharge of solids without interruption.
-
Adjustable Weir Plates: Allows fine-tuning of the liquid pool depth (pond depth) to optimize separation.
-
Intelligent Control System: PLC-based system with touchscreen interface for real-time monitoring and parameter adjustment.
-
Low Maintenance Design: Easy access to key components simplifies cleaning and maintenance.
-
Customizable Configurations: Available with counter-current and co-current flow designs for different separation challenges.
Supplier Information
We are a professional supplier specializing in high-efficiency Decanter centrifuge systems, offering customized engineering solutions, bench-scale testing services, and robust equipment designed for demanding industrial and municipal applications.
