High-Flow Multi-Cartridge Filter Housing – Heavy-Duty Filtration for Large-Scale Industrial Applications

In large-scale industrial applications, filtration demands are substantial. High flow rates, high contaminant loads, and continuous operation require robust equipment that can handle the workload without frequent maintenance interruptions. Single cartridge housings simply cannot meet these demands—they require too many units, too much space, and too much maintenance time.

The DAGYEE High-Flow Multi-Cartridge Filter Housing is engineered for these demanding applications. Designed to accommodate multiple cartridges in a single vessel, it provides high-capacity filtration in a compact footprint. This heavy-duty housing handles flow rates up to 120 cubic metres per hour, significantly reducing the number of housings required and simplifying system design.

Constructed from high-grade stainless steel and featuring a robust closure system, this housing is built for years of reliable service in the most demanding industrial environments. It is the ideal solution for large-scale water treatment, chemical processing, power generation, and industrial manufacturing.

How the System Works

The Process Flow

Step 1: Liquid Entry
The unfiltered liquid enters the housing through the large-diameter inlet connection. The flow is distributed evenly across the multiple cartridges installed inside the vessel.

Step 2: Distribution
An integrated flow distribution system ensures that the incoming fluid is spread evenly across all cartridges. This prevents channeling and ensures that all cartridges are utilized effectively, maximizing filter life and efficiency.

Step 3: Filtration
The fluid passes through the filter cartridges from the outside to the inside (or vice versa, depending on cartridge design). The multiple cartridges work in parallel, each filtering a portion of the total flow. The cartridge media traps suspended particles, contaminants, and impurities based on the cartridge's micron rating.

Step 4: Clean Fluid Collection
The filtered fluid passes through each cartridge core and is collected in the outlet manifold, exiting the housing through the large-diameter outlet connection.

Step 5: Maintenance
When the cartridges become loaded with contaminants, the housing is opened via the quick-opening closure system. All cartridges can be accessed and replaced in a single maintenance operation, significantly reducing downtime compared to servicing multiple single-cartridge housings.

The housing is equipped with vent and drain ports for efficient system startup, pressure relief, and complete drainage during maintenance.

Key Design Features

Technical Specifications

What the System Removes

Pre-Treatment & Installation

nstallation Requirements:

• Level, stable mounting surface (concrete pad or steel frame)

• Access for cartridge change-out (adequate clearance above housing)

• Inlet and outlet piping with appropriate connections

• Pressure gauge ports for system monitoring

• Vent and drain connections for maintenance

Pre-Installation Checks:

• Verify housing material compatibility with process fluid

• Confirm pressure and temperature ratings meet system requirements

• Ensure seals and gaskets are compatible with fluid chemistry

• Check that housing connections match existing piping

• Inspect housing for shipping damage before installation

Installation Steps:

1. Position housing on mounting surface and secure legs

2. Connect inlet and outlet piping (support heavy piping separately)

3. Install pressure gauges in gauge ports

4. Connect vent and drain lines as required

5. Install filter cartridges (ensure correct orientation and sealing)

6. Close and secure housing cover

7. Slowly pressurize and check for leaks

DAGYEE Cartridge Housing Application

Why Choose DAGYEE Cartridge Filter Housing?

FAQ

Q: Are you manufacturer?
A:Yes
Q: What products you provide?
A: Various kinds of filter press, bag filter housing, cartridge filter housing, self cleaning filter, basket filters, filter bag, filter cartridges, filter plate, filter cloth, etc.
Q: How to select the type that needed?
A: When you contact us, we will ask some basic questions to help you select the product type. such as, what is the liquid that you want to filter, flow rate, solid content, etc.
Q: What is the delivery time?
A: It will depends on the order quantity,sometimes when you put order also will influence on the delivery time, once you order from us, we will arrange delivery the cargo as soon as possible.
Q: What is the MOQ？
A: One set

Contact Us

The DAGYEE High-Flow Multi-Cartridge Filter Housing delivers reliable, high-capacity filtration for large-scale industrial applications. Designed for ease of maintenance and long service life, it provides an efficient and cost-effective solution for demanding filtration requirements.

Contact our team for a free consultation and customized housing design for your application.
