Description
Reverse Osmosis Ro Water Treatment System
Product description
The water purification system adopts modular design, so that the system has various characteristics
such as independence, modularization and simple operation. These functions ensure the continuity, stability and reliability of the equipment. In addition, we will also formulate two or more design plans for customers to choose based on the water quality report and URS, including the pretreatment configuration of the combined desalination system, the selection of the distribution system, and the disinfection method. It also provides customers with a complete verification system, including initial design verification, FAT testing in the factory, later installation verification, operation verification and performance verification, and a complete after-sales service system.
Reverse Osmosis Ro System Water Features
- High-precision filter, the pore size is nanometer, the best water quality
-
Automatic switching of manual/electric control system;
-
With self-check function, automatic boiling water system without water point, water full stop, no pressure protection and other safety devices;
- With open RO membrane automatic cleaning and automatic double cleaning of the water tank, it can extend the service life of the RO membrane;
-
With online water quality monitoring (conductivity display), flow and pressure online display functions;
- Equipment integration, simple installation, simple operation, no special responsibilities; Equipment failure has an automatic alarm function;
- High water production, high desalination rate and long service life;
- Core components (pumps, reverse osmosis membranes, electronic control systems, etc.) imported/domestic joint venture brands; The equipment rack is made of stainless steel, the low-pressure pipe is made of UPVC, and the high-pressure pipe is made of SUS304 stainless steel.
Reverse Osmosis Ro System Water Process
1.Raw water pump-- provide the pressure to quartz sand filter/active carbon filter.
2.Quartz sand filter-- get rid of turbidity, suspended matter, organic matter, colloid.
3.Active Carbon filter--Remove the color, free chloride, organic matter, harmful matter.
4.Softener(Optional)--exchange "ions" of calcium and magnesium with the most common and easiest method.
5.Security filter--prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um.
6.High pressure pump-- Provide the high pressure to RO membrane .
7.RO Reverse Osmosis Unit-- main part of the plant. RO membrane's desalting rate can reach 99%.
8.Storage Tank, Achieve treatment effect.
Reverse Osmosis Ro Systems Case
