Description
1-200 m3/h DAF System Clarifier Wastewater Treatment
Innovative flocculation and floatation unit is a unique approach and replacement to traditional DAF (Dissolved air flotation) treatment. The Gas Energy Mixing System can generate better results, handle a much greater contaminant loading, adapt to flow changes and produce much drier solids with a much smaller footprint and using less chemicals than typical DAF systems.
DAF System offers the wastewater industry new technology over traditional DAF Systems, using a smaller footprint, less chemicals and providing drier sludge.
| 50m3/hr Dissolved air flotation Specification | ||
| Parameter | Units | DAF 050 |
| DAF Flow Rate | m3/hr | 50 |
| Total Inlet Solids | mg/L | 500-6500 |
| FOG Removal | % | 80~97 (Application Dependent) |
| TSS Removal | % | 60~99 (Application Dependent) |
| COD Removal | % | 20~80 (Application Dependent) |
| BOD Removal | % | 20~80 (Application Dependent) |
| Power Consumption | kW | 7.2 |
| Footprint | m | 8.4*3.6 |
| Inlet | in | 8 |
| outlet | in | 6 |
| Sludge outlet | in | 6 |
| Vent | in | 4 |
Food Industry Dissolved air flotation Details
- DAF has been successfully applied to the treatment of process and wastewater,water in many industries, including:
- Food industry
- Beverage industry
- Municipal sewage treatment
- Industrial wastewater treatment
- Recycling/Recovery of useful materials
- Water treatment
Application of DAF System Clarifier
- Solids separation upstream of secondary processes such as:
- Oxidation Ditches
- Sequencing Batch Reactors
- Biological Aerated Filters
- Dissolved Air Flotation -Moving Bed Bio Reactors -Membrane Bio Reactors Primary treatment for new plants Grit removal after a coarse screen
- Increase primary or secondary process capacity
- Plant expansion where land is expensive or unavailable
- Dig-free, concrete-free solution for mountainous or earthquake-prone areas
- Combined sewer overflow (CSO) treatment
- Stormwater treatment
DAF System Clarifier Cost-Effective
Our packaged DAF plants are pre-assembled and pre-tested in our controlled facility, often saving 50 percent or more over in-situ construction. They can also be integrated into pre-engineered building systems for increased savings and reduced schedule. Their small footprint also reduces building costs.
Simplicity
Our DAF plants are quiet, simple and easy-to-operate with minimal operator input. They are also supplied complete with chemical dosing, water quality instrumentation, automatic controls and monitoring systems customized to meet local needs.
DAF System Clarifier Standard Features
- Adjustable effluent weir troughs
- Epoxy coated carbon steel tank
- Factory tested
- Seamlessly integrates with other Hydro-Flo offered wastewater products
- Stand alone operation
- Standard units can be manufactured for flows from 5 gpm to 3500 gpm and above, in a single above grade tank
- Structural steel support legs
