DAGYEE Belt Sludge Dewatering Systems: The Complete Technical FAQ

Introduction to DAGYEE Filtration Solutions

About This Guide:

This document is designed for environmental engineers, plant managers, and procurement specialists evaluating Sludge Dewatering technologies. While DAGYEE is a leader in Screw Press technology, we also manufacture robust, high-capacity Belt filter presses for specific high-volume applications. This guide explores the operational principles, maintenance requirements, and performance expectations of our customizable belt systems.

Section 1: Fundamentals & Working Principles

Q1: What is a Belt Filter Press, and how does it differ from other dewatering methods?

A Belt Filter Press is a continuous feed dewatering device that applies chemical conditioning, gravity drainage, and mechanical pressure to remove water from wastewater sludge. Unlike a batch-process Plate and Frame Press, a Belt Filter Press operates continuously, making it ideal for large-scale Wastewater Treatment Plant (WWTP) operations.

The machine uses two tensioned porous belts that sandwich the sludge. These belts meander over a series of rollers with decreasing diameters. As the belts travel, the pressure on the sludge increases, squeezing out water (filtrate) and leaving behind a solid cake.

Q2: Can you explain the three distinct zones of the dewatering process?

The efficiency of a DAGYEE Belt Filter Press relies on three specific processing stages:

Gravity Drainage Zone: After chemical conditioning, the sludge is fed onto the moving porous belt. Here, free water drains through the belt by gravity alone. This stage is critical for increasing the solids concentration before pressure is applied.
Wedge Zone: The two belts (upper and lower) come together to sandwich the sludge. The gap between the belts gradually narrows (like a wedge), applying low pressure to stabilize the sludge cake and prevent it from squeezing out of the sides.
High-Pressure Zone: The sandwiched sludge passes over a series of rollers arranged in a serpentine path. As the belt wraps around these rollers, the tension creates shearing forces and high compressive pressure, forcing the remaining water out of the sludge to achieve maximum Filter Cake Solids.

Q3: Why is Polymer Flocculation necessary for this process?

Polymer Flocculation is the absolute foundation of belt press performance. You cannot dewater raw sludge effectively on a belt press without it.

The Science: Sludge particles are often negatively charged and repel each other. A polymer (typically cationic) neutralizes this charge and bridges the particles together.
The Result: This creates large, strong "flocs" that release free water easily. If the flocculation is poor, the sludge will blind (clog) the filter cloth, and water will not drain in the gravity zone. DAGYEE can assist in selecting the right polymer dosing equipment to pair with your press.

Q4: What types of sludge can a DAGYEE Belt Filter Press handle?

Our systems are versatile Custom Dewatering Solutions capable of handling:

Municipal Sludge: Anaerobic digested sludge or excess activated sludge.
Industrial Sludge: Food processing waste, pulp and paper fiber, textile dyeing sludge, and tannery waste.
Inorganic Sludge: Mining tailings, coal mud, and sand washing slurry.
Note: For extremely oily or sticky sludge, we might recommend our Screw Press, but for high-volume fibrous or inorganic sludge, the Belt Press is often the superior choice.

Section 2: Technical Specifications & Machine Design

Q5: How does the Roller Arrangement affect performance?

The Roller Arrangement is a key engineering feature. A standard DAGYEE unit typically includes:

Drive Rollers: Pull the belt through the system.
Perforated Rollers: Used in the early pressure stages to allow water to escape from both sides of the belt.
Shearing Rollers: Smaller diameter rollers located at the end of the process. The sharper angle of the belt wrap around these small rollers creates higher pressure and shear, squeezing out the last percentage of moisture.

The number and configuration of these rollers determine the total retention time and pressure exerted on the sludge.

Q6: How is the belt tension maintained?

We utilize a Pneumatic Tensioning system (air cylinders) or hydraulic cylinders, depending on the size of the machine.

Consistent tension is vital. If the belt is too loose, the pressure on the sludge drops, and the cake will be wet.
If the belt is too tight, it wears out the bearings and the belt seam prematurely.
DAGYEE’s automated tensioning system ensures the belts remain at the optimal tension continuously, adjusting for belt stretch over time.

Q7: What keeps the belts from sliding off the rollers?

Tracking is a critical issue in belt presses. DAGYEE units are equipped with an automatic Filter Cloth alignment (tracking) system.

Sensors: Mechanical or inductive sensors detect if the belt is drifting left or right.
Correction: A pneumatic cylinder pivots a steering roller. If the belt drifts left, the roller pivots to steer it back to the center. This dynamic alignment prevents damage to the belt edges and ensures safe, unattended operation.

Q8: What materials are used for the frame and components?

As a custom manufacturer, we offer:

Carbon Steel (Epoxy Coated): (As seen in the reference image). Robust, heavy-duty, and cost-effective. Ideal for aggregate, mining, and non-corrosive general industry.
Stainless Steel (SS304/SS316): Recommended for municipal wastewater, food processing, or chemical industries where Corrosion Resistance is mandatory.
The rollers are typically rubber-coated or nylon-coated to provide grip and prevent corrosion.

Q9: What is the Hydraulic Loading Rate of your machines?

The Hydraulic Loading Rate refers to the volume of liquid sludge the machine can accept per hour (m³/hr). This depends on the belt width (e.g., 1 meter, 2 meters, 3 meters).

A 1-meter belt width machine typically handles 10–15 m³/hr.
A 2-meter belt width machine typically handles 30–40 m³/hr.
However, the limiting factor is often the Solids Loading Rate (kg of dry solids per hour). If your sludge is very thick (e.g., 5%), the hydraulic flow must be reduced. DAGYEE engineers will size the machine based on your specific solids load.

Section 3: Operational Performance & Efficiency

Q10: How dry will the sludge cake get?

The final dryness depends heavily on the sludge type:

Biological Sludge: Typically 18% – 25% dry solids.
Paper Pulp/Fiber: Typically 30% – 45% dry solids.
Mineral/Sand Sludge: Can exceed 60% dry solids.

To achieve the highest possible solids content, operators must optimize the Belt Speed Control and belt tension. Running the belt slower allows for a longer "squeeze time" in the high-pressure zone, resulting in a drier cake.

Q11: What is the solids capture rate?

A well-tuned Belt Filter Press should achieve a solids capture rate of >95%. This means that 95% of the incoming Total Suspended Solids (TSS) end up in the sludge cake, and only 5% return to the head of the plant in the filtrate.

If the capture rate is low (cloudy filtrate), it usually indicates poor polymer dosage or a belt mesh that is too open.

Q12: Is the machine suitable for Continuous Operation?

Yes. The Belt Filter Press is designed for Continuous Operation (24/7). Unlike a Filter Press which requires downtime to open plates and discharge cake, the belt press continuously discharges cake and accepts feed. This makes it the preferred choice for large Industrial Sludge Treatment facilities that produce constant waste streams.

Q13: How does the wash water system work?

Because the sludge is pressed into the belt mesh, the belts must be washed continuously on the return loop to prevent blinding.

Spray Bars: High-pressure nozzle bars spray water through the belt.
Filtrate Recycling: To save water, many clients collect the filtrate (the water squeezed out of the sludge), filter it, and reuse it as wash water. DAGYEE can design the system to accommodate Filtrate Recycling to lower your operational costs.

Section 4: Comparison (Belt Press vs. Others)

Q14: Why choose a Belt Press over a Screw Press?

While DAGYEE manufactures both, the Belt Press has specific advantages:

High Volume: For very large flows (e.g., >50 m³/hr), a single large Belt Press is often cheaper than multiple Screw Presses.
Inorganic Solids: Belt presses handle gritty, abrasive inorganic sludge (sand/mining) better than Screw Presses, which can suffer from screw wear.
Fiber Handling: Belt presses are excellent for fibrous sludge (paper/pulp) because the fibers mat together well on the belt.

Q15: Why choose a Belt Press over a Centrifuge?

Energy Cost: A centrifuge spins at 3000 RPM and uses massive amounts of electricity. A Belt Press moves slowly and uses significantly less energy.
Noise: Belt presses are quieter.
Visibility: With a belt press, you can see the process. If flocculation is poor, you see it immediately in the gravity zone. With a centrifuge, it is a "black box."

Section 5: Maintenance & Troubleshooting

Q16: What are the common maintenance items?

To ensure longevity, the following maintenance is required:

Belt Replacement: The polyester belts are consumables. Depending on usage and sludge abrasiveness, they typically last 2,000 to 4,000 hours.
Bearings: Grease the roller bearings regularly.
Spray Nozzles: Clean the wash water nozzles to ensure the belt is being cleaned across its full width.
Scraper Blades: The doctor blades at the Sludge Cake Discharge point eventually wear down and need replacement to ensure clean removal of the cake from the belt.

Q17: Troubleshooting: Sludge is squeezing out from the sides of the belt.

This is a common issue called "side-seepage."

Cause 1: The sludge is not fully drained in the Gravity Drainage Zone. If it is still liquid when it hits the Wedge Zone, it will squirt out. Solution: Improve flocculation or slow down the belt.
Cause 2: Feeding too much sludge. Solution: Reduce the feed pump speed.
Cause 3: Belt tension is too low.

Q18: Troubleshooting: The filter cake is sticking to the belt and not discharging.

Cause 1: The scraper blade (doctor blade) is worn or not touching the belt. Solution: Adjust or replace the blade.
Cause 2: Sticky sludge. Solution: Increase the wash water pressure to help release the cake, or adjust the polymer type.
Cause 3: Belt speed is too fast.

Section 6: Commercial & DAGYEE Customization

Q19: What information does DAGYEE need to provide a quote?

To engineer the correct solution, we need:

Sludge Type: (e.g., Biological, Paper Pulp, Mining).
Solids Concentration: (Inlet % DS).
Flow Rate: (m³/hr or GPM).
Desired Cake Dryness: (%)
Daily Operating Hours:
Material Requirements: (Standard Carbon Steel or Stainless Steel).

Q20: How does DAGYEE support international installation?

We design our machines for ease of setup.

Pre-assembly: The main frame and rollers are assembled in our factory.
Documentation: We provide detailed manuals, electrical diagrams, and foundation drawings.
Support: We offer video guidance for belt installation (which is the most complex part) and commissioning support via video conference or on-site engineering dispatch if required.

Summary: Why Choose DAGYEE?

At DAGYEE, we understand that wastewater treatment is not one-size-fits-all. Whether you need a compact Screw Press for oily sludge or a heavy-duty Belt Filter Press for a high-capacity Wastewater Treatment Plant (WWTP), we have the engineering expertise to build it.

Our Belt Filter Presses are designed with robustness in mind—featuring heavy-duty frames, precise Pneumatic Tensioning, and advanced Filter Cloth alignment systems to ensure trouble-free operation.
