Mining Industry Sludge Dewatering Specialist Belt filter press for Tailings and Process Water
The DAGYEE Mining Industry Sludge Dewatering Specialist Belt Filter Press is a core piece of equipment engineered specifically for the demanding process water treatment in mining. Built to tackle the challenges of high-hardness and highly abrasive solids in mining wastewater, it delivers efficient, continuous dewatering of tailings, concentrates, and various mineral sludges through a reinforced structure, optimized filtration path, and reliable automation. It ensures the quality of process water for reuse and dramatically reduces sludge disposal costs, making it the ideal choice for modern, environmentally responsible mines.
How belt filter presses work
Enhanced Flocculation: Utilizes specialized flocculants in a high-shear mixer to form dense flocs tailored to mineral slurry characteristics.
Gravity Thickening/Drainage: Flocculated slurry rapidly releases a large amount of free water on a coarse mesh belt, boosting subsequent efficiency.
Wedge Pre-Pressing & Forming: Enters a graduated wedge zone, subjected to linearly increasing pressure to release interstitial water and form a uniform sludge mat.
High-Pressure Shear Dewatering: The sludge mat undergoes powerful shearing and compressive forces in an "S"-shaped path of multiple press rollers, removing capillary water to form a hard, solid cake.
Automatic Discharge & Cleaning: The dry cake is scraped off, and the belts are thoroughly cleaned by high-pressure jets, ensuring continuous high-efficiency operation.
Belt filter presses Technical
|
Sludge kinds |
Input concentration % |
Capacitym3/h.m |
DS capacitykg/h.m |
Moisture of cake% |
PAM consumption%(DP/DS ) |
|
Unconcentrated aerobic sludge |
0.5~1.5 |
15~30 |
150~300 |
~80(+2) |
2~5 |
|
Concentrated aerobic sludge |
2~4 |
6~12 |
200~300 |
~80(+2) |
2~5 |
|
Digested sludge |
3~6 |
7~15 |
300~400 |
<80 |
2~5 |
|
Unconcentrated primary sludge |
0.8~2.0 |
18~35 |
300~400 |
<80 |
2~5 |
|
Concentrated primary sludge |
3~5 |
6~12 |
300~400 |
≤80 |
2~5 |
|
Paper making activated sludge |
0.5~2.5 |
15~35 |
200~400 |
<78 |
3~7 |
|
Printing and dyeingmixed sludge |
1~3 |
10~25 |
180~350 |
75-85 |
3~10 |
Belt filter presses Advantage
BEARING FRAME Made of two very thick carbon steel plates (on request, SST), fixed to each other by means of profiles and welded to form a stiffen perfectly levelled unit. The whole structure is protected by sand-blasting type Sa 2.5, then by a zinc-aluminium alloy hot spraying and finally covered by a layer of bicomponent polyurethanic resin. Bolts and nuts are made of SST A2 AISI 304. (Ref. A)
ROLLERS The pressing, tensioning, transmission and sludge discharge rollers are protected by a layer of 8mm of rubber. The motorized pressing roller and the trajectory correction one are coated by 8 mm. of rectified rubber layer. All the rollers are supported by ball bearings type ‘Y’ which are suitably sized and guarantee a perfect impermeability. (Ref. B
BELTS TRACTION SYSTEM Models with belts width of 800, 1200, 2000 mm.: it consists of a worm motor variator with speed manual adjustment, directly keyed to the roller; Models with belts width of 1600, 2500, 2600, 3000 mm.: it consists of an epicyclic motor variator connected to a traction roller by a toothed crown and chains protected by carters. (Ref. C)
BELTS GUIDE SYSTEM Pneumatic type with proportional action probes to keep the belts continuously centered and one upon the other. (Ref. D)
BELTS TENSION SYSTEM It consists of pneumatic jacks with air springs which keep the belts tensioned. (Ref. E)
BELTS WASHING SYSTEM It consists of spray header pipes equipped with nozzles which can be cleaned by a specia plan (Ref. F)
Belt filter presses Features
-
Fully Automatic PLC Control: Enables hands-off operation from feeding, conditioning, dewatering to cleaning.
-
Intelligent Belt Tracking System: Ensures stable belt operation, prevents deviation and wear, and extends service life.
-
Multi-Stage Dewatering Design: Combines gravity, wedge pre-pressing, and high-pressure shear for deep dewatering.
-
Efficient High-Pressure Washing: Equipped with stainless steel nozzles for thorough cleaning and effective prevention of belt clogging.
-
Heavy-Duty Corrosion-Resistant Structure: Core frame and contact parts made of high-quality stainless steel for corrosion resistance and long life.
-
Modular Design: Easy installation, maintenance, and part replacement, minimizing downtime.
Belt filter presses Benefits
Increased Water Reuse Rate: Produces clear filtrate suitable for direct reuse in the process circuit, conserving fresh water intake.
Significantly Reduced Haulage Costs: Converts liquid slurry into a dry, solid cake, reducing volume by over 80%, drastically cutting tailings transportation and storage expenses.
Enhanced Operational Stability: Mining-grade reliability minimizes unplanned downtime, ensuring continuous production.
Strong Adaptability to Complex Slurries: Effectively handles sludges from various minerals (e.g., iron, copper, gold, coal) with different characteristics.
DAGYEE Mining Expertise: We possess extensive experience serving mining projects, offering professional technical support from selection to commissioning.
Belt filter presses application industries
-
Municipal Wastewater Treatment Plants
-
Petrochemical & Refining
-
Food & Beverage Processing
-
Pulp & Paper Industry
-
Textile & Dyeing
-
Metallurgy, Plating & Mining
-
Pharmaceutical & Chemical Industry
The DAGYEE Upgrade: It's Not Just an Equipment Replacement, It's an Investment in Your Future.
Choosing our upgraded Belt Filter Press means you will immediately start a new chapter of Low Operating Cost operation. It is a smart decision with a rapid return on investment, ensuring your wastewater plant remains efficient, economical, and competitive for the next decade and beyond.
