Description
WHAT IS LAMELLA CLARIFIER
The Plate Pack System Gravity Clarifier is an innovative solid-liquid separation unit that combines multiple inclined plate modules with gravity-driven clarification. This integrated system maximizes settling efficiency through optimized plate configuration and hydraulic distribution, providing superior performance in a compact footprint. Designed for continuous operation with minimal energy consumption, it effectively removes suspended solids across various water and wastewater treatment applications.
HOW DOES lamella clarifier WORKS
When using, you can choose to add coagulant. The method is to install inclined plate component with an inclination angle of 60 degrees above the suspended layer of sludge. Suspended solids in the raw water, solids or floc alum flowers formed by adding a coagulant are added to the surface area of the inclined plate Accumulate into a thin mud layer, rely on gravity to slide back to the suspended sludge layer, and then sink into the mud hopper. The sewage pipe is discharged into the sludge tank for further treatment or comprehensive utilization. The supernatant gradually rises to the drain of the water collection , which can be directly discharged or reused.
RANGE OF APPLIOCATION
- Mining
- Metal finishing
- Treat groundwater
-
Industrial process water
- Pre-treatment ahead of membrane filters
- Municipal wastewater
- TSS solids particulate removal
- Dissolved solids and metals precipitation
- Leachate clarification
- Cooling tower water clarification
- Surface raw water treatment
- Water recycling/reuse
- Backwash from sand filters
AVAILABLE DESIGNS
- smaller footprint
-
Large effective settling area
-
Improved overflow rates 2 to 4 times
-
Can be used for a long time
- Normal use without clogging, Even clogging is provided with backwash device
- Less possibility for injury
LAMELLA CLARIFIER EQUIPMENT SPECIFICATIONS
The Plate Pack System Gravity Clarifier represents the evolution of sedimentation technology, delivering unprecedented efficiency in a compact, energy-neutral design. Its combination of proven gravity separation principles with advanced plate pack configuration makes it ideal for both new installations and facility upgrades where space, efficiency, and reliability are paramount. The system's adaptability to various water qualities and flow conditions ensures consistent performance while minimizing operational complexity and costs. As water treatment requirements become increasingly stringent and space constraints more challenging, this technology offers a sustainable solution that meets today's needs while accommodating future demands. With global installations across multiple industries, it has demonstrated proven reliability and performance in the most demanding applications.
