Quartz sand filter is a pressure filter.It can be used quartz sand as the filter media. When the influent water flows through the filter layer from top to bottom, the suspended solids and viscose particles colloids, sediment and rust in water. The pump is pressurized to pass the raw water through the filter medium to remove the suspended matter in the water,Thereby reducing the turbidity of the water.
Quartz sand filtration is an important unit used in advanced wastewater treatment, wastewater reuse and feedwater treatment. It is function to remove more pollutants that have already flocculated in the water. It achieves the purpose of purifying water through the interception, sedimentation and adsorption of the filter material.
QUARTZ SAND FILTER STRUCTURE
1. Upper Service Hole
2. Filter Inlet
3. Anthracite Layer
4. Fine Sand Layer
5. Coarse Sand Layer
6. Filter Outlet
7. Sand Support Layer
8. Filter Element
9. Side Service Hole
RANGE OF APPLICATION
Used for industrial water, domestic water and municipal water supply systems that require effluent turbidity ≤ 5mg / L to meet drinking water quality standards;
Removal of suspended solids and solids in industrial wastewater;
It can be used as a pretreatment equipment in the softening and desalination system of ion exchange method, and a coarse filtration equipment for industrial water supply with low water quality requirements.
Removed by use of Sand filter
Iron, Manganese, Arsenate and some priority chemicals
