Description
Static Screen Wastewater Description
Static screen water is designed to provide trouble free liquid separation. The open screen design accommodates peak hydraulic flows and the deep influent head box reduces influent turbulence while delivering an even flow over the weir crest. A pivoting flow control baffle plate is provided to enhance even flow distribution and promote faster fluid removal by directing the fluid into the screen.
This is a wedge wire bending screen, used in the physical processing unit of a static screening treatment plant. The static sieve has no driving mechanism. And it does not require energy.
Static Screen Wastewater Works
Influent pumped into the inflow chamber through the inlet of the pipe. As the water level rises, it will flow under the wage weir and the pivoting baffle. Liquids and solids flow through the screen, and Liquids falls through the screen, while gravity and more screening push the captured solids toward the discharge point. The wastewater passes through the filter enters distribution chamber and flows through the outlet tube. The drip-proof assembly at the bottom of the filter directs excess water to the waste chamber. When the solids reach the bottom of the screen, they slide into the container, conveyor or other suitable receiving equipment. Dagyee offers a variety of rear screen and dewatering equipment. To assemble the most cost-effective screening system. Welcome to consult.
Static Screen Wastewater Model
Static Screen Wastewater Feature
A Better Environment for Beaver Pond
Whitewater Reuse
Broke Thickening
Helps Nut Grower Recycle Wastewater
Screening fire sprinkler water
Storm water screening
Better Dairy Pen Waste Management
Textiles and laundries
Static Screen Wastewater Application
Fruit and vegetable canning
Wine producers and distilleries
Meat and processed meals industry
Slaughterhouse
Fish processing
Breweries and dairies
