Description
PTFE MBR Flat Membrane
MBR technology addresses a wide range of wastewater treatment applications where high quality effluent is required, either to meet regulatory requirements or for reuse. membranes ensure high quality and one stop responsibility. MBR targets Biological Oxygen Demand (BOD), Total Suspended Solids (TSS), Bacteria, Total Coliforms, Ammonia, Nitrogen, and Phosphorus.
MBR also eliminates many pharmaceuticals from the waste stream, which is a growing concern for natural habitats and drinking water. With extensive experience with groundwater remediation, can bring solutions for emerging contaminant challenges such as PFAS and other compounds that may be present in the system effluent.
MBR Module Table
| Model |
Membrane area (m2) |
Capacity (m3/d) |
A mm |
B mm |
C mm |
D mm |
E mm |
F mm |
G mm |
| DF50-50 | 25 | 10-15 | 912 | 677 | 1185 | 153 | 1110 | 516 | 713 |
| DF50-80 | 40 | 16-24 | 1370 | 677 | 1185 | 153 | 1110 | 516 | 1170 |
| DF50-100 | 50 | 20-30 | 1674 | 677 | 1185 | 153 | 1110 | 516 | 1476 |
| DF50-120 | 60 | 24-36 | 1980 | 677 | 1185 | 153 | 1110 | 516 | 1780 |
MBR Module Discharge Targets
Biological Oxygen Demand (BOD) <5.0 mg/L
Total Suspended Solids (TSS) <5.0 mg/L
Ammonia-N <1.0 mg/L
Turbidity <0.5 NTU
Total Phosphorus <0.1 mg/L
Total Nitrogen <5.0 mg/L
Enhanced Nutrient Removal Design can achieve lower effluent results:
Total Phosphorus <0.05 mg/L
Total Nitrogen <3.0 mg/L
MBR Module Applications
- Greenfield & Retrofit Projects
- Existing Infrastructure Tie-ins
- Municipal WWTPs
- Temporary or Interim Sewage Facilities
- New Residential Developments
- Hotels, Resorts & Restaurants
- Off-Grid & Remote Municipal Plants
- New Commercial Developments
