Bag Filter Housing – High Dirt-Holding Capacity for High-Solids & High-Flow Applications

When your filtration application involves high solids loading, large particle sizes, or high flow rates, standard cartridge filters simply don't cut it. They clog too quickly, require frequent change-outs, and drive up operating costs. You need a filtration solution that can handle the load without constant maintenance interruptions.

The DAGYEE Bag Filter Housing is designed for exactly these demanding conditions. Instead of small-surface-area cartridges, it uses large filter bags with significantly higher dirt-holding capacity. A single bag filter can hold several times more contaminants than a cartridge filter before needing replacement.

This housing is engineered for heavy-duty industrial applications. Constructed from corrosion-resistant stainless steel, it handles high flow rates, high solids loading, and continuous operation. Single or multi-bag configurations provide flexible capacity from small pilot systems to large industrial operations. For plant managers dealing with high-solids streams, bag filter housings deliver reliable performance with less maintenance.

Why Bag Filters for High-Solids Applications

Bag filters are fundamentally different from cartridge filters. A cartridge filter rolls media around a core, creating a relatively small filtration surface. A filter bag, on the other hand, is a simple open bag with a large surface area. This design difference has significant practical implications.

High Dirt-Holding Capacity
The large surface area of a filter bag means contaminants are spread over a much wider area. The bag can hold a substantial amount of solids before the differential pressure becomes excessive. In high-solids applications, this translates directly to longer service life and fewer change-outs.

Depth Loading
Filter bags capture particles throughout the thickness of the media. Larger particles are trapped near the surface, while finer particles penetrate deeper into the media. This depth loading mechanism provides high removal efficiency and extends service life.

Higher Flow Rates
Because the surface area is large, a filter bag can handle higher flow rates than a cartridge filter of comparable size. A single bag filter can often replace multiple cartridge filters in the same application.

Lower Operating Cost
Fewer change-outs mean lower labor costs and less consumable waste. While the initial cost of a bag filter housing may be higher than a cartridge housing, the total cost of ownership over time is often significantly lower.

Simple Change-Out
Changing a filter bag is simple and quick. Open the housing, lift out the spent bag, drop in a new one, and close the housing. No tools are required for most designs. Minimal downtime means maximum production.

How the System Works

The operational principle of the sanitary filter housing is similar to standard multi-cartridge housings, with significant enhancements for hygiene and cleanability.

The Process Flow

Step 1: Product Entry
The liquid product enters the housing through the sanitary inlet connection. The flow is distributed evenly across the multiple cartridges installed inside the vessel.

Step 2: Filtration
The product passes through the filter cartridges. The cartridge media traps particles, microorganisms, and other contaminants based on the cartridge's micron rating. All surfaces in contact with the product are smooth and crevice-free.

Step 3: Clean Product Collection
The filtered product passes through each cartridge core and is collected in the outlet manifold, exiting through the sanitary outlet connection.

Step 4: Cartridge Retention
The filter cartridges are securely held in place by sanitary cartridge adaptors. Standard connections include 222 O-ring or 226 O-ring configurations with sanitary bayonet locking.

Step 5: Sanitization and Cleaning
The housing is designed for Clean-in-Place (CIP) and Steam-in-Place (SIP) operations. Vent and drain ports allow complete drainage and sanitization without disassembly.

Step 6: Maintenance Access
When required, the housing is opened via the hygienic clamp closure system. Cartridges can be replaced quickly without specialized tools, and all wetted surfaces are accessible for manual cleaning if needed.

Key Design Features

Feature	Benefit
Stainless Steel Construction	Corrosion resistance, long service life in harsh environments
Single or Multi-Round Configurations	Flexible capacity from 1 to 60 cartridges
Various Cartridge Lengths	Accepts 5", 10", 20", 30", and 40" cartridges
Multiple Connection Types	DOE, 222 O-ring, 226 O-ring, or threaded options
High-Pressure Rating	Suitable for demanding process conditions
Easy-Opening Closure	V-band clamp, swing bolts, or eye bolts for quick access
Vent and Drain Ports	Complete drainage and pressure relief during maintenance
Optional Surface Finish	Electropolished or bead-blasted surfaces
Various Seal Materials	Viton, EPDM, or NBR O-rings for chemical compatibility
Mounting Options	Legs, brackets, or flanged connections as needed

Technical Specifications

What the System Removes

Pre-Treatment & Installation

Installation Requirements:

• Level, stable mounting surface

• Adequate clearance for cartridge change-outs

• Sanitary piping connections

• Access for CIP/SIP systems

Sanitation Process (CIP/SIP):

1. Rinse with purified water

2. Clean with appropriate cleaning solutions

3. Rinse with purified water

4. Steam sterilize (SIP)

5. Cool and prepare for operation

Maintenance:

• Visual Inspection: Regular inspection of seals and connections

• Cartridge Change-Out: When differential pressure reaches setpoint

• Seal Replacement: Annually or as needed

• Surface Inspection: Check for damage, corrosion, or contamination

• Validation: Regular revalidation per GMP requirements

DAGYEE Cartridge Housing Application

Industrial Water Treatment – removes suspended solids, sand, and sediment from cooling water, boiler feed, and process water. Protects pumps, valves, and heat exchangers from wear and fouling.

Chemical Processing – removes impurities and particles from chemical streams. Maintains product purity and protects sensitive equipment.

Oil and Gas – removes solids from produced water, injection water, and process streams. Handles high pressures and variable conditions.

Wastewater Treatment – removes sludge and suspended solids from industrial and municipal wastewater streams. Reduces load on downstream treatment processes.

Cooling Water – removes debris and particles from cooling tower water. Protects heat exchangers and condensers from fouling.

Food and Beverage – clarifies liquids before processing. Removes particulates to maintain product quality and consistency.

Mining – removes solids from process water, tailings water, and slurry streams. Handles abrasive and high-solids conditions.

Paint and Coatings – removes lumps, skins, and contaminants from liquid paints, coatings, and inks.

Why Choose DAGYEE Cartridge Filter Housing?

Feature	Customer Value
Stainless Steel Construction	Corrosion resistance and long service life
Wide Cartridge Compatibility	Accepts standard cartridges from leading manufacturers
High-Pressure Rating	Suitable for demanding process applications
Easy Maintenance Access	Quick-opening closures reduce downtime
Flexible Configuration	Single to multi-round options for any flow rate
Customizable Finish	Electropolished, bead-blasted, or mirror finish available
Multiple Seal Options	Viton, EPDM, NBR, Silicone for chemical compatibility
Industry Standard Design	ASME code optional, CE certified
Factory Tested	Quality assured before shipment
Competitive Pricing	Cost-effective without compromising quality

FAQ

Q: Are you manufacturer?
A:Yes
Q: What products you provide?
A: Various kinds of filter press, bag filter housing, cartridge filter housing, self cleaning filter, basket filters, filter bag, filter cartridges, filter plate, filter cloth, etc.
Q: How to select the type that needed?
A: When you contact us, we will ask some basic questions to help you select the product type. such as, what is the liquid that you want to filter, flow rate, solid content, etc.
Q: What is the delivery time?
A: It will depends on the order quantity,sometimes when you put order also will influence on the delivery time, once you order from us, we will arrange delivery the cargo as soon as possible.
Q: What is the MOQ？
A: One set

Contact Us

The DAGYEE Bag Filter Housing delivers reliable, high-capacity filtration for high-solids and high-flow applications. With high dirt-holding capacity, easy maintenance, and durable stainless steel construction, it is the ideal solution for demanding industrial environments.
