Submersible Mixers Description
Dagyee anti-corrosion submersible mixer is specially optimized and upgraded for various harsh high-corrosion industrial wastewater working conditions, solving the problems of easy rust, corrosion and short service life of ordinary mixers in chemical sewage environments. The whole machine is made of high-quality SUS316L stainless steel, which has excellent resistance to acid, alkali, salt and various chemical medium corrosion. On the basis of the original sealing structure, we add reinforced anti-corrosion coating and upgraded composite mechanical seal accessories, which can effectively avoid water ingress, rust damage and component aging caused by long-term immersion in corrosive water bodies. The optimized hydraulic circulation structure and polished impeller surface ensure that the equipment can still achieve uniform and stable stirring and circulating effects in complex chemical water media with various impurities, and all products have passed long-term corrosion immersion tests to adapt to harsh industrial working conditions.
Submersible Mixers Component
- Motor
- Upper bearing
- Seal monitoring&indication
- Solids deflection ring
- Mechanical seal
- Axial flow propeller
- Bracket
- Control System
- Corrosion resistant shell
| Componente | Material |
|---|---|
| Shell | Stainless steel/GG25 cast iron |
| Impeller | Stainless steel/Fiberglass Polyurethane |
| Shaft | ASTM431 or 420 stainless steel |
| Mechanical seal | Corrosion resistant cemented tungsten carbide/or silicon carbide |
| Guide rod | ASTM304 Stainless steel |
| Lifting bracket | ASTM304 Stainless steel |
| Lifting cable | ASTM304 Stainless steel |
| Fasteners | ASTM321 Stainless steel |
Submersible Mixers Parameter
| Model | Power (kW) | Current (A) | Rotary speed (rpm) | Impeller diameter (mm) | Force (N) | Weight (kg) |
|---|---|---|---|---|---|---|
| SMB0.85/8-260/3-740/C/S | 0.85 | 3.4 | 740 | 260 | 163 | 55/58 |
| SMB1.5/6-260/3-980/C/S | 1.5 | 4.4 | 980 | 260 | 290 | 55/58 |
| SMB2.2/8-320/3-740/C/S | 2.2 | 5.9 | 740 | 320 | 582 | 74/77 |
| SMB4/6-320/3-980/C/S | 4 | 10.8 | 980 | 320 | 609 | 74/77 |
| SMB1.5/8-400/3-740/S | 1.5 | 5.6 | 740 | 400 | 382 | 76/80 |
| SMB2.5/8-400/3-740/S | 2.5 | 7.3 | 740 | 400 | 575 | 76/80 |
| SMB3/8-400/3-740/S | 3 | 8.6 | 740 | 400 | 642 | 78/82 |
| SMB4/6-400/3-980/S | 4 | 10.3 | 980 | 400 | 1010 | 80/84 |
| SMB4/12-620/3-480/S | 4 | 14 | 480 | 620 | 1230 | 240/245 |
| SMB5/12-620/3-480/S | 5 | 18.2 | 480 | 620 | 1420 | 240/245 |
| SMB7.5/12-620/3-480/S | 7.5 | 28 | 480 | 620 | 1963 | 255/270 |
| SMB10/12-620/3-480/S | 10 | 32 | 480 | 620 | 2361 | 255/270 |
Energy-saving Submersible Mixers Selection
This anti-corrosion energy-saving submersible mixer is specially selected for industrial wastewater treatment projects with corrosive media, mainly applicable to chemical plants, printing and dyeing factories, pharmaceutical factories and electroplating factories. It is very suitable for water bodies with unstable pH value, residual chemical components and corrosive impurities, and is the preferred equipment for harsh working conditions that require 24-hour continuous underwater operation. In terms of scene matching, it is targeted at medium and small corrosive sewage tanks and water bodies with high liquid impurity content and high viscosity. While ensuring strong anti-corrosion performance, the equipment retains high-efficiency energy-saving performance, which can effectively reduce the energy consumption cost of long-term operation of industrial sewage treatment systems for users.
Submersible Mixers Installation Method
Dagyee anti-corrosion submersible mixer is equipped with a full set of anti-corrosion stainless steel guide rail installation system, all supporting accessories including guide rails, brackets, bottom fixing frames and connecting fasteners are made of anti-rust and anti-corrosion materials, completely avoiding rust, oxidation and loosening in corrosive water bodies. The standard guide rail lifting installation mode is adopted, which supports free underwater lifting and maintenance. The equipment can be inspected and repaired at any time without stopping the sewage treatment system or draining water, which improves the overall operation efficiency of the project. For special-shaped tank bodies and special installation requirements, we can also provide customized inclined installation and fixed suspension installation schemes to meet the installation and operation needs of different industrial sewage tanks.
Submersible Mixers Factor
The maximum medium temperature does not exceed 40°C;
The PH value of the medium is between 5-9;
The density of the medium does not exceed 1150kg/m3;
The diving depth is generally not more than 20m.
Submersible Mixers Features
A propeller with specially formed blades;
Resistance to aggressive liquids;
A double mechanical seal;
Economical operation with no special demands on maintenance;
The mixer can also be supplied with a lowering device which provides continuous adjustment of the height and direction during operation.
Submersible Mixers Application
Livestock and poultry manure and urine storage tank;
Biogas fermentation tank;
Urine transport channel;
Oxidation pond;
Food factory raw material mixing;
Industrial Wastewater Pool;
Sewage treatment plant storage tank.
What DAGYEE Does Differently
I won't waste your time with marketing fluff. Here's what we actually do:
Material choices that make sense — We offer standard cast iron and stainless. But we also do full SUS316L on every wetted part — not just the shaft, but impeller, fasteners, hub, guide cone — when the job calls for it. We don't try to upsell you. We recommend what fits.
Complete mounting systems — Guide rails, winches, stainless cables, lifting frames. We supply the whole package. Maintenance can be done from above — no one has to climb into the tank.
International voltage compliance — We build units for 480V/60Hz for North American projects. It's not an afterthought; it's designed in.
No guesswork in selection — We ask about your tank, your media, your process conditions. Then we run the numbers and recommend a specific model — not the one we happen to have in stock, but the one that actually works for your site.
Summary
QJB model codes follow a consistent pattern. Once you learn it, you can read any manufacturer's spec sheet:
And if you need something outside the standard box — different material, different voltage, different mounting — that's where we come in.
DAGYEE — Submersible Mixers Built for Your Application
Need a hand selecting the right model? Send us your tank dimensions, media type, and operating conditions. We'll run the numbers and recommend a specific unit — no obligation, just advice.
